About
The YO Meter Pulse input accepts connection to potential-free contacts. The device will not count pulses if the input is connected to contacts with any potential. Device input can detect pulses with different contact debounce times. This parameter is configurable and by default is 47 ms – up to max. 10 pulses per 1 s (boundary range 1-50 pulses per 1 s depends on the contact debouncing setting).
Connectivity & sensors
LoRaWAN class
Class A
Sensors
Pulse countTemperatureHumidity
Additional radios
BLE
Specifications
IP rating
IP67
Battery
3 x AA (3 x 1.5V)
Dimensions
64 × 88 × 42 mm
Weight
126.5 g
